GPS in FPV Drones

Introduction

GPS (Global Positioning System) plays an essential role in FPV drones, providing features such as accurate positioning, return-to-home (RTH), waypoint navigation, and altitude hold. Modern FPV drones use GPS modules in combination with a flight controller (FC) to enhance flight safety and automation.

Why Use GPS in FPV Drones?

• Return to Home (RTH): Automatically brings the drone back to its takeoff point in case of signal loss.
• Position Hold: Enables the drone to hover in a fixed location without drifting.
• Waypoints Navigation: Preprogrammed routes for autonomous flying.
• Speed & Altitude Monitoring: Essential for long-range flights.

Types of GPS Modules for FPV Drones

1. UBlox Series GPS Modules:
   • UBlox NEO-M8N – One of the most common FPV GPS modules, providing high accuracy and fast satellite acquisition.
   • UBlox SAM-M8Q – Compact, lightweight, and ideal for micro drones.
   • UBlox NEO-6M – Older but still widely used in budget FPV setups.
2. Beitian GPS Modules:
   • Beitian BN-220 – Affordable and small, best suited for lightweight drones.
   • Beitian BN-880 – Features an integrated compass, ideal for precise navigation.
3. DJI GPS Modules:
   • Found in DJI flight controllers, providing advanced GPS-based features.
   • Often integrated with DJI FPV systems.

GPS Module Connection with Flight Controller (Circuit Diagram)

Most GPS modules connect to the flight controller via UART (TX/RX) ports. Some also have a compass (I2C connection) for accurate heading detection.

Basic Wiring Diagram:

If using a GPS module with a compass, additional I2C connections are required:

Setting Up GPS in Betaflight

1. Connect GPS to the Flight Controller (UART Port).
2. Enable GPS in Betaflight Configurator:
   • Go to the Ports tab and enable GPS on the correct UART.
   • In the Configuration tab, turn on GPS and set the protocol (e.g., UBlox).
3. Calibrate the Compass (if applicable).
4. Verify GPS Lock: Ensure the module acquires at least 6-8 satellites before takeoff.

Best Practices for Using GPS in FPV Drones

• Mount the GPS Module Away from Electronics: Reduces interference from ESCs and VTX.
• Use a GPS Module with a Compass: Improves navigation and heading accuracy.
• Wait for a Full GPS Lock Before Arming: Prevents inaccurate RTH points.

Conclusion

Integrating a GPS module into an FPV drone provides enhanced safety, navigation, and automation. Choosing the right GPS module and correctly wiring it to the flight controller ensures reliable performance, particularly for long-range and autonomous flights.

Stay tuned for more FPV drone insights!
