Introduction
A flight controller (FC) is the brain of an FPV drone, responsible for processing data from sensors and controlling motors to stabilize flight. Choosing the right flight controller significantly affects the drone’s performance and capabilities.
Types of Flight Controllers
- SpeedyBee F405 V3 – Popular for its wireless tuning capabilities.
- Betaflight F7 – High-performance FC supporting advanced flight modes.
- CC3D – Entry-level FC, best for beginners.
- Pixhawk – Ideal for autonomous drones with GPS capabilities.
Flight Controller Features
| Feature | Description |
| Processor (MCU) | F4, F7, or H7 chips determine processing power and latency. |
| Gyroscope | Detects movement and adjusts drone stability. |
| OSD (On-Screen Display) | Displays telemetry data on FPV goggles. |
| UART Ports | Used to connect peripherals like GPS, receivers, and VTX. |
| Barometer | Helps in altitude hold and navigation. |
Popular Flight Controller Software
- Betaflight – Most commonly used for freestyle and racing drones.
- INAV – Best for GPS and navigation-based flights.
- ArduPilot – Designed for autonomous missions and mapping.
Wiring a Flight Controller
Flight controllers have multiple connections:
- ESCs – Connected to motor outputs.
- Receiver – Linked via SBUS, PPM, or ELRS.
- VTX (Video Transmitter) – Connected for FPV transmission.
- GPS – Used for autonomous flights and return-to-home functions.
Choosing the Right Flight Controller
- Skill Level – Beginners should start with easy-to-configure FCs like CC3D.
- Flight Style – Freestyle pilots prefer low-latency FCs with high refresh rates.
- Budget – Higher-end FCs offer more features but may not be necessary for casual flying.
- Compatibility – Ensure compatibility with ESCs, VTX, and other drone components.
Conclusion
The flight controller is the heart of an FPV drone, impacting stability, flight performance, and responsiveness. Whether you’re racing, freestyling, or flying long-range, selecting the right FC ensures a smooth and efficient flying experience.
Stay tuned for our next blog on Motors and Propellers for FPV Drones!
